Specifications

Technical specifications

Parts List

structure size

processor	CPU Main frequency Power consumption	Onboard i5-8265U CPU (4C/8T/15W) 1.6GHz up to 3.9GHz 15W
store	Memory Hard disk	8G DDR4 Samsung M.2 500G
Graphics Engine	Graphics	Intel® UHD Graphics for 8th Generation Intel® Processors
Front panel interface	Kushiguchi GPIO Wi-Fi	4 x COM (COM5 & 6 are not full signal， COM6 can be set to RS232/485 by jumper) 1 x GPIO 2 x Wi-Fi interface (reserved, must be used with M.2 Wi-Fi module) Wi-Fi
Rear panel connector	Power switch/indicator Power supply interface Display interface Serial port Ethernet port USB Audio GND	1 x power switch with power indicator 1 x external power switch and indicator 1 x DC12V power supply 2 x HDMI 2 x COM (COM2 can be set to RS232/422/485 by jumper) 2 x Intel Gigabit LAN ( i211-AT ) 4 x USB2.0 ; 4 x USB3.0 1 x LOUT 1 x shell ground
Adapter	Power input Power output	AC 100~240V/1.5A 50/60Hz DC 12V/5A
Expansion Slot	M.2	1 x M.2 (NGFF) Key-B Slot (3042/3052, PCIE + USB3.0(Premium-U) + USB2.0, support 4G/5G, with1 * SIM Card Header) 1 x M.2 (NGFF) Key-E Slot (PCIE+USB2.0, Wi-Fi+BT, 2230)

processor

CPU

Main frequency

Power consumption

Onboard i5-8265U CPU (4C/8T/15W)

1.6GHz up to 3.9GHz

15W

store

Memory

Hard disk

8G DDR4

Samsung M.2 500G

Graphics Engine

Graphics

Intel® UHD Graphics for 8th Generation Intel® Processors

Front panel interface

Kushiguchi

GPIO

Wi-Fi

4 x COM (COM5 & 6 are not full signal，
COM6 can be set to RS232/485 by jumper)

1 x GPIO

2 x Wi-Fi interface
(reserved, must be used with M.2 Wi-Fi module) Wi-Fi

Rear panel connector

Power switch/indicator

Power supply interface

Display interface

Serial port

Ethernet port

USB

Audio

GND

1 x power switch with power indicator

1 x external power switch and indicator

1 x DC12V power supply

2 x HDMI

2 x COM (COM2 can be set to RS232/422/485 by jumper)

2 x Intel Gigabit LAN ( i211-AT )

4 x USB2.0 ; 4 x USB3.0

1 x LOUT

1 x shell ground

Adapter

Power input

Power output

AC 100~240V/1.5A 50/60Hz

DC 12V/5A

Expansion Slot

M.2

1 x M.2 (NGFF) Key-B Slot (3042/3052, PCIE + USB3.0(Premium-U) +

USB2.0, support 4G/5G, with1 * SIM Card Header)

1 x M.2 (NGFF) Key-E Slot (PCIE+USB2.0, Wi-Fi+BT, 2230)

Name	quantity	√ Standard / × Optional	Remark
Host	1	√
screw	1	√	Expansion screws
Whip Antenna	1	√	Bendable Wi-Fi Antenna
Suction cup antenna	1	√	4G All Network Antenna
Connector	1	√	Including power cord, network port
Power Adapter	1	√	AC100~240V input DC16.8V 2A output

Physical parameters	size	220121.670mm
