Specifications

Technical specifications

Parts List

structure size

Hardware specifications	UWB standard Output power Current Input voltage	802.15.4z ch9 (-13)dBm/MHz (adjustable) <=100ma 3.3V( +- 5%)
Software Specifications	Positioning mode Communication protocol	AOA+TOF
Antenna parameters	Positioning frequency UWB antenna Bluetooth antenna	0.1~10HZ adjustable Can be used with IPEX1 external antenna Built-in ceramic antenna
Reliability	Working temperature Storage stability Working humidity Antistatic level	-30℃ ~+75℃ -40℃ ~+85℃ 95%(Non-condensing) 无

Hardware specifications

UWB standard

Output power

Current

Input voltage

802.15.4z ch9

(-13)dBm/MHz (adjustable)

<=100ma

3.3V( +- 5%)

Software Specifications

Positioning mode

Communication protocol

AOA+TOF

Antenna parameters

Positioning frequency

UWB antenna

Bluetooth antenna

0.1~10HZ adjustable

Can be used with IPEX1 external antenna

Built-in ceramic antenna

Reliability

Working temperature

Storage stability

Working humidity

Antistatic level

-30℃ ~+75℃

-40℃ ~+85℃

95%(Non-condensing)

无

Serial number	Pin Name	Function	Describe
1	RES

Physical specifications	size	20mm 20mm3mm

Applications

The digital agriculture management platform can realize accurate dispatch and real-time monitoring of the labor force, improve labor efficiency and management level, and ensure operation safety. The digital agriculture management platform will summarize and analyze the data to make it more intuitive and detailed to understand the overall agricultural production management situation and use this data for macro-control.
