| Hardware specifications | UWB standard Bluetooth Output power Wireless interface Storage | 802.15.4a, ch2 5.0 Maximum power > -21dBm/MHz (adjustable by software) UWB: 2xMMCX connector (side plug/direct plug optional) Bluetooth: IPEX4 nor flash: 32Mbit nand flash: 1G or more (8mm*6mm) |
|---|---|---|
| Power consumption parameters | Current | Average current: 400mA Startup current: 500mA Emission current: 600mA |
| Software Specifications | Positioning mode UWB effective distance User capacity Positioning scenario Positioning frequency | oF 1400 meters @ 850Kbps (dual antenna) without obstruction and interference; 700 meters @ 850Kbps without obstruction and interference Small area: 200 @ 1Hz System capacity: unlimited 0D + 1D + 2D Fixed frequency can be set: 10Hz, 5Hz, 2Hz, 1Hz, 0.5Hz, 0.2Hz, 0.1Hz |
| Physical specifications | size weight | 55*35*11mm (including antenna seat) ＜40 |
|---|---|---|
| reliability | Working temperature Storage temperature Working humidity Anti-static level | -40℃~85℃ -40ºC~85ºC 0%～95% non-condensing 15KV, contact: 8KV Compatible |
